Mô tả sản phẩm
Design Features and Benefits
1、 Heavy duty bearing housing structure.Reliable,big loading capability,smooth operation
2、There is separate impeller chamber for big size pump. It is convenient for impeller installation
3、 Controllable pitch impeller,impeller blade angle can be adjusted according operation condition
4、 Reliable impeller mounting method,rotor can be bidi- rectional operation
5、 High tensile strength alloy shaft,small deflection, smooth operation
6、 Highly anti-corrosive shaft bush is adopted to protect the shaft from corrosion
7、Double mechanical seal is adopted for more reliable sealing performance
8、Molded elbow welding,smoother liquid flow
Main Parameters
Flow Range:150~28000m³/h
Head:1.5~6.5m
Pressure:1.0MPa
Temperature:-20℃~+150℃
Application
It is mainly used in refinery,petrochemi- cal industry,coal chemical plants, power plant,salt making,phosphoric acid production,environment protection project.
Typical Performance
NO. | Customer/Project Information | Pump Model | Performance Parameters | Matched Power (kW) |
1 | Xian Ningke Chemical Industry (Taixing) Co., Ltd. | Forced Circulation Pump300-III | Q=700m³h,H=4m,Water，115℃ | 30kW-4 |
2 | Jineng Chemical(Qihexi) Co., Ltd. | Forced Circulation Pump500-III | Q=2400m³/h,H=4m, Water，80℃ | 75kW-8 |
3 | China Tianchen Engineering Co., Ltd. | Forced Circulation Pump900-III | Q=7500m³/h,H=4m,First-Effect Caustic Solution ,55℃ | 185kW-4 |
