Design    Features    and    Benefits

1、 Heavy   duty   bearing   housing   structure.Reliable,big loading capability,smooth operation

2、There is separate impeller chamber for big size pump. It is convenient for impeller installation

3、 Controllable  pitch  impeller,impeller  blade  angle  can be adjusted according operation condition

4、 Reliable impeller mounting method,rotor can be bidi- rectional operation

5、 High   tensile   strength   alloy   shaft,small   deflection, smooth operation

6、 Highly anti-corrosive shaft bush is adopted to protect the shaft from corrosion

7、Double mechanical seal is adopted for more reliable sealing  performance

8、Molded elbow welding,smoother liquid flow

Main Parameters

Flow Range:150~28000m³/h

Head:1.5~6.5m

Pressure:1.0MPa

Temperature:-20℃~+150℃

Application

It is mainly used in refinery,petrochemi- cal     industry,coal     chemical     plants, power     plant,salt     making,phosphoric acid  production,environment  protection project.

Typical Performance
